Description
Self-braking M2AO – MAO, with DC brake
The M2AO – MAO series three-phase, self-braking , enclosed, externally ventilated motors, manufactured in accordance with the main international standards, in particular IEC 34 and 72, are available in frame sizes from 56 to 160 and higher upon request, in single-pole configurations (2, 4, 6, and 8), as well as in dual-pole configurations, with both single and double windings.
Available power ratings range from 0.04 to 18.5 kW.
They feature a die-cast aluminum housing , IP 55 protection, class F insulation, and shielded, lifetime-lubricated bearings. The brake is powered by a single-phase rectifier bridge.
Self-braking M2AY – M2Y, with AC brake
The M2AY – M2Y series three-phase, self-braking , enclosed, externally ventilated motors, manufactured in accordance with the main international standards, in particular IEC 34 and 72, are available in frame heights from 71 to 200 and higher upon request, in single-pole configurations (2, 4, 6, and 8), as well as in dual-pole configurations, with both single and double windings.
Available power ratings range from 0.06 to 37 kW.
They feature a die-cast aluminum housing for sizes up to 160, cast iron for larger sizes, IP 55 protection, class F insulation, and shielded, life-lubricated bearings. The brake is powered by a three-phase power supply.
